Screen Size

55"

Resolution

1,920 x 1,080 (FHD)

Input

HDMI, DP

Output

DP, Audio (55" only)

Bezel Width

(Off-bezel) 1.2 / 1.2 / 1.2 / 1.2mm (U/B/L/R)
(On-bezel) 8.7 / 8.7 / 9.3 / 12.4mm (U/B/L/R)
(Seam) 8.2 mm

Dimension (W x H x D)

(Head)
1x2: 1,390.8 x 1,227.0 X 7.9 mm
1x3: 2,079.3 x 1,227.0 x 7.9mm
(T-Con Box) 312.2 x 213.4 x 16 mm
(Signage Box) 412.6 x 222.4 x 64.3 mm

Operation Temperature

0°C to 40°C

Operation Humidity

10 % to 80 %

Power Supply

100-240 V~, 50/60 Hz

Power Type

Built-In Power

Safety

UL / cUL / CB / TUV / KC

EMC

FCC Class "A" / CE / KCC

OPS type compatible

Yes

External Media player Attatchable

Yes

Content Management Software

SuperSign Premium

Control and Monitoring Software

SuperSign C

Basic

Remote Controller (include battery 2ea), Power Cord, QSG, HDMI Cable (3M x 1ea for connection between T-Con box and signage box), Power Hanness Cable (3M x 1ea for connection between T-Con box and signage box), IR receiver, Regulation Book, Phone to RS232C Gender, Signage Box Jack Cover, T-Con Box Jack Cover, Signage Box Mounting Bracket, T-Con Box Mounting Bracket, FFC Cables (350mmx4ea, 1600mmx4ea for connection between panel and T-Con box), Phone to Phone (4pin) Cable, DP Cable, LAN Cable, LC Cable (VLC)
