Screen Size

55"

Panel Technology

OLED

Aspect Ratio

16 : 9

Surface Treatment

Hard coating (2H), Anti-reflection treatment of the front polarizer (Reflectance Typ.1.0%)

Orientation

Portrait & Landscape

Contrast Ratio

100,000 : 1

Brightness

100/400 cd/m2 (APL 100 % / 25 %) * Average Picture Level

Life time (Min.)

20,000 hrs

Native Resolution

1,920 x 1,080 (FHD)

Operation Hours

18 hrs / 7 days (moving video only)

Response Time

1 ms (G to G), 8 ms (MPRT)

Viewing Angle (H x V)

178 x 178

External Control

RS232C (1+1), RJ45 (1+1), IR Receiver, USB 2.0 (2), USB 3.0 (2)

Output

Audio (1+1)

Dimension (W x H x D)

Head : 48.3" x 27.7" x 0.3" (Edge depth : 0.36") Signage Box : 18.5" x 15.9" x 3"

Bezel Width

2, 2, 2, 2 mm (U, B, L, R *Off-bezel)

Bezel Color

Silver

Packed Weight

80.5 lbs

Carton Dimensions (W x H x D)

53" x 38.9" x 10.6" (Inner)

Weight

Head : 46.3 lbs / Signage Box : 17.6 lbs

Operation Humidity

10 % to 80 %

Operation Temperature

32° F to 104° F

Power Type

Built-In Power

Power Supply

Built-In Power

Power off

0.5 W

DPM

3 W

Safety

UL / cUL / CB / TUV / KC

ErP / Energy Star

Yes / NA

OPS Type Compatible

Yes

External Media Player Attachable

Yes

SuperSign W-Lite

Yes

SuperSign C

Yes

Optional

OPS Kit (KT-OPSA), Fixed Ceiling Mount Kit (ACC-CF-EH5C), Rotational Ceiling Mount Kit (ACC-CR-EH5C), Wall Mount Kit (ACC-W-EH5C), Stand Kit 1 (ACC-S-EH5C), Stand Kit 2 (ACC-S1-EH5C), Signage Box Cover (ACC-C-EH5C)

Basic

Remote Controller (included 2ea batteries), Power Cord, QSG, Mini HDMI Cable (3M x 2ea, for connection between head and signage box), Power Hanness Cable (3M x 2ea, for connection between head and signage box), Regulation Book, Phone to RS232C Gender, Jack Cover, Signage Box Mounting Bracket

UPC

TBD

WARRANTY

3-Year Limited Warranty (Parts and Labor) | Extended Warranties Available
