Panel Size

3LCD 15mm (0.59")

Resolution

WXGA (1280 x 800)

Light Output (Brightness) ANSI Lumens

3000 (Normal), 2460 (Eco), 2100 (Eco-2)

Contrast Ratio

10,000:1

Lamp Life (Hours)

5000 (Normal), 10000 (Eco-2)

Lens

Built-in

Lens Zoom

Manual Zoom x 1.2

Lens Focus

Manual Focus

Throw Distance

0.9 - 11.5m

Distance to Width Ratio/ Throw Ratio (:1)

1.5 (Wide), 1.8 (Tele)

Diagonal Display Size

30 - 300"

Digital Keystone Correction

Horizontal ± 30°, Vertical ± 30°

Digital Input

HDMI/MHL x1, HDMI x1 (Supporting HDCP decoding)

Analogue Input

15-pin Mini D-Sub x 2, RCA Jack x 1

Video Output

15-pin Mini D-Sub x 1

Audio Input

3.5mm Stereo Mini Jack x 1, RCA Jack (L/R) x 1

Audio Output

3.5 mm stereo mini jack x1

RS-232C Control

1 x 9-pin D-Sub

Wireless LAN

Yes (Optional)

Wired LAN

Yes

USB Type A

Used for PC-less presentation, wireless network or optional wireless pen tablet TB-1

USB Type B

Used for Remote control mouse or PC screen display

Power Supply

AC 100 - 120 V / AC 220 - 240 V (50/60 Hz)

Operating Power Consumption

310W

Standby Power Consumption

Less than 0.5W

Weight

3.1Kg

Dimensions (W x H x D) (Without feet)

320 x 85 x 245mm

Noise

37dB (Normal), 32dB (Eco), 29dB (Eco-2)

Filter Life (Hours)

5,000

Computer

IBM Compatible VGA, SVGA, XGA, WXGA, WXGA+/ SXGA/ SXGA+/ UXGA (compressed), MAC16"

Video

525i(480i), 525p(480p), 625i(576i), 625p(576p)1125i(1080i@50/60), 750p(720p@50/60), 1125p(1080p@50/60)

Supplied Accessories

Power Cable (1.8m) x1, Computer Cable (2m) x1, IR Remote Control Unit x1, AA Batteries x2, Lens Cap x1, Adapter Cover x1, Security Label x1, Application CD (for network, etc.) x1, CD User Manual x1, Concise User Manual x1

Optional Accessories

USB wireless adaptor USB-WL-11N. Wireless pen tablet TB-1 is optional.

Remote Control

HL03031

Replacement Lamp / Filter

DT01481

Projector/ Lamp Warranty

3 years / 6 months (for education and extended warranties please contact your local dealer.)
